Smart mattress

Hallòw® supports the care of tomorrow

Produktlogo Hallòw Smart

Anti-decubitus prophylaxis mattress with Hallòw® system

  • Applicable up to stage 2 (EPUAP)
  • Middle risk (Norton-, Braden-, Waterlow-scale)
Produktbild smarte Matratze

Integrated sensors in the mattress transmit data to the Hallòw platform during use.

This information can be converted into the
following incidents and alarms:

  • The patient is in or out of bed,
  • the patient is sitting on the edge of the bed and
  • the position the patient is in.
Smartbox für die Hallòw-Matratze

Smart box

  • Installation under the lying surface of the bed
  • Backup battery for emergency power included (4 hours without main power)
  • Plug and play

Are you interested? Contact us:

Contact form

Characteristics

  • Cover: two-coloured for easy differentiation between top and bottom, removable, washable up to 95°C, disinfection by wiping,
    disinfectant-proof*, suitable for disinfection with chlorine*, ultrasonically welded seams
  • Visco foam top layer with a cube structure
  • Smart ready

Special features

  • 19 pressure sensors
  • 1 piezoelectric sensor (vibration measurement)
  • Supports all communication protocols (WLAN, LAN, LTE-M, Dect, Bluetooth and Relay)
Schlafende Frau liegt in einem Pflegebett, die Sensoren der Hallòw-Matratze werden dargestellt
Pfleger überprüft die Verkabelung der Hallòw-Matratze

Technical data

  • Breathable open-cell foam
  • Cover material virus- and bacteria-proof accord. ASTM 1670 + 1671
  • Waterproof but permeable to water vapour
  • Bi-elastic cover to minimise shear forces
  • Optimised pressure relief
  • CE-marking MDR 2017/745
  • Maintenance-free
  • Flame retardant DIN EN 1021-1 & 1021-2
  • Easy to disinfect
  • Chlorine max. 1000 ppm
  • Patient weight: 0–130 kg
  • Not reversible

Sizes

(width x length x height in cm)
90 x 200 x 14
100 x 200 x 14
More sizes available

Hallòw® platform

With the help of Hallòw, you receive live information about your patients. The workload and workflow of nursing staff are significantly optimised. Individual alarm functions can be configured. Hallòw provides you a reliable support, especially in the current times when personnel shortages and excessive workloads are the order of the day.

  • Quick and easy handling
  • Improved reaction time
  • 24/7 fall and absence notifications
  • More efficient care documentation
  • Improved positioning management
  • Improves the well-being of care staff and reduces sick days
  • Individually adjustable to patients needs and reduces disturbances

Visit us:

hallow-smart.eu

*For more details see instructions for use.
